13053530 OMNITRONIC UHF-502 2-Channel Wireless Mic System 863-865 MHz

2-channel UHF PLL microphone system

• 2-channel multifrequency receiver unit and 2 hand-held microphones with UHF PLL technology
• 80 fixed frequencies selectable per channel
• Pilot tone technology (PLL) and noise squelch for interference-free operation
• Operation range with line of sight approx. 50 meters
• Automatic frequency scan (AFS) finds interface-free channels
• Easy and error-free synchronization between receiver and transmitters via infrared signal
• LCDs for RF reception level, AF audio level, frequency and channel
• Parallel operation of up to 4 transmission channels is possible without any interference
• Lock function avoids accidental changing of the transmission channel
• 2 separate channels with volume controls
• Balanced XLR output per channel
• 6.3 mm jack for mixed signal output, switchable mic/line
• Jack cable included
• Non-diversity system with two removable antennas (BNC connection)
• Microphones with mute switch and color caps for distinction on stage
• Operation of the receiver unit via supplied power unit
• Operation of the microphones via 2 x 1.5 V batteries (type AA), not included
• Receiver unit with aluminum front panel and dimensions for 483 mm rack installation (1U)
• License-free and approved in the EU
• On/off/mute-switch: Yes

13053531 OMNITRONIC UHF-502 Bodypack incl. 863-865MHz, Lavalier (CH A red)

Pocket transmitter with lavalier microphone for channel A and UHF-502 microphone system

• Pocket transmitter for UHF-502 microphone system with the same carrier frequency
• Incl. lavalier microphone
• Headset microphone optional
• Pilot tone technology (PLL) for interference-free operation
• Infrared interface for easy and error-free synchronization with the receiver via infrared signal
• LCD for battery capacity and transmission channel
• Sensitivity adjustable
• Transmitting power 5 mW/10 mW, switchable
• LED battery indicator
• Belt clip
• Operation via 2 x 1.5 V batteries (type AA), not included
• License-free and approved in the EU
• On/off/mute-switch: Yes

13053532 OMNITRONIC UHF-502 Bodypack 863-865MHz, incl. Lavalier (CH B blue)

Pocket transmitter with lavalier microphone for channel B and UHF-502 microphone system

• Pocket transmitter for UHF-502 microphone system with the same carrier frequency
• Incl. lavalier microphone
• Headset microphone optional
• Pilot tone technology (PLL) for interference-free operation
• Infrared interface for easy and error-free synchronization with the receiver via infrared signal
• LCD for battery capacity and transmission channel
• Sensitivity adjustable
• Transmitting power 5 mW/10 mW, switchable
• LED battery indicator
• Belt clip
• Operation via 2 x 1.5 V batteries (type AA), not included
• License-free and approved in the EU
• On/off/mute-switch: Yes

13053522 OMNITRONIC UHF-502 Headset for Bodypack

Headset for UHF-502 Bodypack

• Lightweight design for optimum wearer comfort
• One-sided cable run
• Connection cable with 3-pin mini XLR plug
• Foam windscreen
• Color: black

13053530 OMNITRONIC UHF-502 2-Channel Wireless Mic System 863-865 MHz

System:   Non-diversity, 2 channels
Carrier frequency:   UHF 863-865 MHz
Color code:   CH A = red, CH B = blue
Receiving frequencies:   80
Coverage:   50 m (with line-of-sight)
RF power output:   10 mW
Modulation method:   FM
Frequency stability:   10 ppm
Sensitivity:   -95 dB
S/N ratio:   >80 dB
Selectivity:   >80 dB
T.H.D.:   <0.1 %
Audio outputs:
Mic:   2 x XLR, bal.
Mix:   6.3 mm jack, unbal.
Power supply:
Receiver:   12 V DC via supplied power unit (100-240 V AC, 50/60 Hz)
Microphones:   2 x 1.5 V battery, type AA
Dimensions, weight:
Receiver:   253 x 482 x 51 mm (L x W x H), 1.9 kg
Microphones:   50 x 240 mm (D x L), 230 g (w/o batteries)
Frequency band:   UHF 863 - 865 MHz
Power consumption:   5 W
Material:   Metal
Frequency range:   40 - 18000 Hz
Weight:   2,5 kg

13053531 OMNITRONIC UHF-502 Bodypack incl. 863-865MHz, Lavalier (CH A red)

Carrier frequency:   UHF 863-865 MHz
Color code:   CH A = red, CH B = blue
Receiving frequencies:   100
Coverage:   50 m (with line-of-sight)
RF power output:   5 mW (LO), 10 mW (HI)
Modulation method:   FM
Frequency stability:   10 ppm
S/N ratio:   >90 dB
T.H.D.:   <1 %
Audio input:   mini XLR (supplies 5 V)
Battery:   2 x 1.5 V, type AA
Power consumption:   approx. 100 mA
Dimensions (L x W x H):   108 x 66 x 22 mm
Lavalier microphone:
Type:   Electret
Directivity pattern:   Cardioid
Sensitivity:   -47 dB
Impedance:   680 ohms
S/N ratio:   >63 dB
Power supply:   2-10 V DC
Connection:   cable with 3-pin mini XLR plug
Cable length:   approx. 1 m
Capsule:   9.7 x 5.2 mm
Frequency band:   UHF 863 - 865 MHz
Weight:   0,217 kg
Frequency range:   50 - 15000 Hz

13053532 OMNITRONIC UHF-502 Bodypack 863-865MHz, incl. Lavalier (CH B blue)

Carrier frequency:   UHF 863-865 MHz
Color code:   CH A = red, CH B = blue
Receiving frequencies:   100
Coverage:   50 m (with line-of-sight)
RF power output:   5 mW (LO), 10 mW (HI)
Modulation method:   FM
Frequency stability:   10 ppm
S/N ratio:   >90 dB
T.H.D.:   <1 %
Audio input:   mini XLR (supplies 5 V)
Battery:   2 x 1.5 V, type AA
Power consumption:   approx. 100 mA
Dimensions (L x W x H):   108 x 66 x 22 mm
Lavalier microphone:
Type:   Electret
Directivity pattern:   Cardioid
Sensitivity:   -47 dB
Impedance:   680 ohms
S/N ratio:   >63 dB
Power supply:   2-10 V DC
Connection:   cable with 3-pin mini XLR plug
Cable length:   approx. 1 m
Capsule:   9.7 x 5.2 mm
Frequency band:   UHF 863 - 865 MHz
Weight:   0,217 kg
Frequency range:   50 - 15000 Hz

13053522 OMNITRONIC UHF-502 Headset for Bodypack

Type:   Electret
Directivity pattern:   Cardioid
Sensitivity:   -49 dB
Impedance:   680 ohms
S/N ratio:   >63 dB
Power supply:   2-10 V DC
Connection:   cable with 3-pin mini XLR plug
Cable length:   approx. 1 m
Capsule:   D = 9.7 mm
Weight:   0,027 kg
Frequency range:   50 - 15000 Hz
