The multifrequency receiving unit RM-105 serves as a replacement part or as an extension for the PA system W.A.M.S.-05. The receiving unit operates in the UHF range of 863.100 - 864.900 MHz. The frequency range is divided into 16 channels, which can be selected as desired. The hand-held microphone HM-105, the transmitter module ALT-105 and the pocket transmitter TM-105 can be used for a wireless signal transmission to the receiving unit as they are tuned to the same frequencies.
Multifrequency receiving unit for W.A.M.S.-05
- Receiver as UHF PLL system, suitable for W.A.M.S.-05 system
- Applicable for operating with a second receiver channel or as a replacement
- Operation in the low-interference UHF-band (863,1-864,9 MHz) with 16 frequencies selectable
- LCD for channel and frequency
- Volume control
- LEDs for carrier and audio signals
- License-free and approved in the EU
| System: | PLL multifrequency receiver |
| Carrier frequency: | UHF 863.100-864.900 MHz |
| Range: | approx. 30 m |
| Frequency range: | 70-16000 Hz |
| Power supply: | 12 V DC, 185 mA |
| Output voltage: | 130 mV max. |
| Dimensions (L x W x H): | 88 x 37 x 134 mm |
| Weight: | 115 g |
| Length: | 13.4 cm |
| Height: | 3.7 cm |
| Width: | 8.8 cm |
OMNITRONIC RM-105 Receiver Module WAMS-05
- Gamintojas: OMNITRONIC
- Prekės kodas: 13106986
- Pristatymas: Išparduota
- 224.30€
